Mould Products







  Product Introduction
Meet the China national standard GB/T6892-2006 and Europe standard EN12020-1, (2001) and American Standard ANSI H35.2-2003.
We are a trustworthy supplier, constant business partner and sincere friend.Our engineers is specialized in this field for more than 20 years,with experience on heavy crosssection heat sink profiles extrusion aluminum tools.
Processing methods commonly used include: turning by NC lathe, milling by CNC (computer numerical control) machine , grinding by NC machine, drilling, wire cutting, EDM electrical-discharge machining.
We have got ISO9001:2000 certification and the durability of our extrusion dies exceeds the similar products about 50% .Our excellent R&D staff guarantee that we can make any kind of extrusion die according to customer requirements. The biggest extrusion die in our factory is about 1700mm.The high tech of die manufacture helps to build a good reputation for our company. And we are well known in this industry both home and abroad.

Application: Our extrusion die is widely used in producing aluminum profiles, which is used in the food industry, the packaging industry, construction field and decoration, ships and pressure vessels, high-speed rail, aviation component products, such as easy-to-pull tanks , chemical storage containers, partition houses, mobile rooms, offshore pipelines, aircraft skeleton, window profiles, door profiles, profiles for curtain wall, the profiles for solar etc.The more commonly used specifications include 6061 and 6063 series.


Product details

Molds for Aluminum Profile Production Line / Aluminum Extrusion Die
Item	Aluminum Extrusion Die/slide Die/Hollow die/aluminum profile extrusion molds
Material	Forged H13 steel or customer-specified (P20, 420SS).
Surface treatment available	Nitriding
Die size range	Up to 1700mm
Wall thickness	Min:0.3mm
Hardness	HRC48-52
Way of Heating	Vacuum heat treatment by frequency induction furnace
Before Die cutting	Die design will be offered for customer's approval
Lead time	7-10 days
Package	Plywood Box, Carton Box



Die after-sales service

1	After each die test, if there is any feedback on any problem, we will provide the mold correction plan or suggestion within 48 hours
2	For customers who has given orders regularly, the sales manager will bring technical staff to visit every six months to understand and summarize the main problems in the use of molds, and give feedbacks to the designers for later promotion and improvement
3	For customers whose purchase volume reaches a certain scale, the company can send die corrector to the customer site for a period of time to carry out mold system correction and maintenance
